DREAMPOD II FRIDGE FAN
Three Way Fridge Ventilation Upgrade

2012 Version:- The fans are replaced with new "silent" models.

Fig.1 70C thermostat

Fig.1 70C thermostat available from Jaycar CAT. NO. ST3833
Fig.2 12v-120mm Nanoflux magnetic levitation bearing fan.

Fig.2 12v-120mm Nanoflux magnetic levitation bearing fan available from Jaycar CAT. NO. YX2584



Mounting The Fan & Connecting It Up

Fig.3 Top vent showing fan mounted using cable ties, Make sure you attach it so that it is blowing out the vent NOT in

Fig.3 Top vent showing fan mounted using cable ties,
Make sure you attach it so that it is blowing out the vent NOT in
Fig.4 Wiring diagram.

Fig.4 Wiring Diagram




Positioning the Thermostat

Fig.5 Outside view showing thermostat.
Fig.5 Outside view showing thermostat position is about 3" from the RHS of this pipe adjusted so fan only operates when hot
Fig.6 Close-Up of the thermostat.
Fig.6 Close-Up of the thermostat attached with cable ties




Refitting the Top Vent

Fig.7 Replacing the vent showing the fan connection.
Fig.7 Replacing the vent showing the fan connection
Note:- small sections of water hose
provide extra sound isolation.
Fig.8 Only the cable ties are seen.
Fig.8 Only the cable ties are seen.



Internal Circulation Fan

Fig.9 90mm Internal FanFig.10 The '3M' Hooks
Fig.9 90mm Internal Fan                                         Fig.10 The '3M' Hooks

NOTE:- This is a smaller fan than the external one also Nanoflux magnetic levitation bearing Jaycar CAT. NO. YX2582.
Both fans are virtually silent in operation you wouldn't know they are running. Wires are fed in via the drain hose.

Attach to the top of the fridge with "3M" brand hooks. It's mounted diagonally to blow
from left to right across the evaporator fins as the LHS on my fridge is the side that
used to ice up. Now its always a constant internal temperature and doesn't ice up at all.
12v to run both fans is available at the back of the fridge but be careful to observe
polarity or fans will not operate.
